MAG6242 24-Port Gigabit Network Switch - 翻译中...

Downstream port

24 10/100/1000M RJ45;

Upstream port

2 Gigabit SFP optical slots Combo

Switching Capacity

64Gbps

Forwarding Rate

42Mpps

MAC Address Table

Support 4K MAC address table, dynamic and static address table

Supports automatic aging of MAC address table, bidirectional learning

Protocol Standard

IEEE 802.3i 10Base-TX;

IEEE 802.3i 10Base-TX;

IEEE 802.3ab/z 1000Base-TX;

IEEE 802.3x Flow Control;

IEEE 802.3af DTE Power via MDI;

IEEE 802.3at DTE Power via MDI;

ANSI/IEEE802.3N-Wa;

IEC61000-4-2(ESD)15KV(air)，8KV(contanc)

Lightning Protection Characteristics

meet IEC61000-4-2 (ESD) ±15KV (air), ±8KV (contanc); can withstand 8/20us 24A (12A) energy

Environmental Requirements

Long term working temperature: -10~55 ℃

Long term working relative humidity: 10%~90% (without condensation)

Power Supply

AC:

Rated voltage range: 100-240V AC; 50/60Hz

Maximum voltage range: 90-264V AC; 50/60Hz

Product Dimension

440*180*44.5mm(W*D*H)

Product Weight

(kg)

＜2.6Kg

Note: Bare machine, including the weight of AC power supply, excluding the weight of DC adapter, excluding packaging materials and accessories.
